HYGIENIC 80

The new Hygienic 80 design incorporates the proven performance and self-cleaning, self-draining capabilities of the current dual and triple nozzle Tankman models, but it also offers a more hygienic appearance — with no exposed gears, a larger selection of nozzle orifices, less component parts and improved performance.

The Hygienic 80 effectively and thoroughly cleans the tanks and process vessels, with a minimum of cost and maintenance, for a variety of applications in the brewing, chemical processing, food processing and pharmaceutical industries.

Both dual and triple-nozzle models are hydraulically driven by the cleaning solution and will provide a thorough 360-degree cleaning pattern every 45 revolutions.

The hydraulic drive gives it longer life and more reliability, without any internal drive gears to worry about. Ease of field maintenance!

Specifications

  • Minimum Opening: 5.52" / 140 mm
  • PSI / Bar: 50-200 / 3.4-13.8
  • GPM / LPM: 25-135 / 95-511
  • Radius: 25 ft / 7.6 m

HYGIENIC 80 OUTSIDE
